Feature

1. Operation interface

1.1. Adopting TFT-LCD true color display screen,

1.2. Dual operation mode of touch screen buttons and physical buttons,

1.3. Equipped with a dedicated button for displaying centrifugal force, displaying both set and operating parameters,

1.4. During operation, parameters can be changed at any time without the need for shutdown. The operation interface is intuitive, simple, and convenient to use;

2. The control system adopts Yingruien microcontroller and Infineon driver module;

3. The motor adopts a high torque AC brushless motor, which operates stably and has low noise;

4. Safety system: equipped with various warning functions such as overspeed, overtemperature, imbalance, undervoltage, overvoltage, etc;

5. Equipped with a three-level damping damping device and a special combination of damping devices, the motor operates smoothly, safely, and reliably, preventing sample resuspension and achieving excellent centrifugal effect.

6. It has 10 speed acceleration and 10 speed deceleration control functions, and can store 20 sets of user-defined programs, making it easy to call commonly used programs. The last program used is when the computer is turned on.

7. It has multiple specifications of aviation forged aluminum rotors (only angle rotors) and a variety of polyamide fiber adapters to choose from, suitable for 0.2mL to 250mL centrifuge tubes or reagent bottles; Various types of MTP microporous plates, PCR plates, cell culture plates, and deep well plates can be centrifuged.

8. Humanized design:

8.1 The door lock adopts a silent electromechanical integrated motor, which is convenient to use.

8.2 The biosafety airtightness angle rotor adopts a silicone rubber integral sealing ring, which can avoid aerosol leakage and fully ensure the safety of staff and laboratory environment.

8.3 The shell adopts security devices such as all steel spray molding, integrated stamping formed steel front face, rear austenitic 304 stainless steel centrifugal chamber, and three-layer steel protective sleeve, which are sturdy and durable, and ensure the safety of staff and laboratory use.

9. Temperature control:

9.1 Using fluorine-free refrigeration compressor units and environmentally friendly refrigerant R404a,

9.2 Temperature control range: -20 ℃~+40 ℃,

9.3 Temperature adjustment accuracy: ± 1 ℃

9.4 Temperature parameters can be set during the operation of the centrifuge;

9.5 has a prefabricated cooling function that can quickly cool down to the set temperature;

9.6 has standby cooling function, which can maintain the set temperature in standby mode;

9.7 has the function of heating and defrosting.

10. Optional IoT function;

10.1 Optional equipment operation status recording, analysis and statistics function;

10.2 Optional remote control function;

10.3 Can be equipped with functions such as fault diagnosis assistance.

11. Multiple optional angular and horizontal rotors (1.5ml 2.0ml 5ml 10ml 50ml 100ml 500ml), as well as enzyme labeled rotors with 2x2x96 wells.

1. Working conditions:

1.1 Working power supply: voltage AC220V, frequency 50Hz;

1.2 Working environment: temperature 5-40 ℃, humidity ≤ 80%;

2. Maximum capacity: 4 × 500 ml

3. Maximum speed: 20600 r/min

4. Maximum centrifugal force: 29280 × G

5. Speed accuracy: ± 50r/min

6. Control and drive system: AC variable frequency motor, microcomputer control

7. Refrigeration system: Fluorine free refrigeration compressor unit (R404a)

8. Temperature control range: -20 ℃~+40 ℃

9. Temperature control accuracy: ± 1 ℃

10. Running programs: 20

11. Total power: 1.8 Kw

12. Timing range: 1-99h59min

13. Noise: ≤ 60 dB

14. Rotor recognition: Automatic rotor recognition function

15. Weight: 110 Kg

16. Overall dimensions (length x width x height): 630 × seven hundred and sixty × 400 mm

Applied in fields such as biochemistry, healthcare, food safety, life sciences, agriculture and forestry, animal husbandry, blood banks, blood stations, biological products, pharmaceutical products, etc., to separate, precipitate, and concentrate samples.
